GPS III

The new GPS III is the result of a continuing programme of development of the GPS II.
Manufacturer part number: 3525
Availability: Out of stock
Manufacturer: Powerbox Systems
£94.50
Description

The new GPS III is the result of a continuing programme of development of the GPS II, which has now been on the market for a good eight years. The software has been completely restructured, enabling us to improve the unit’s performance significantly. Amongst other new features, measured values are now transferred with greater precision.

The GPS III automatically detects the make of radio control system or PowerBox/iGyro to which it is connected, and sets up correct communication completely automatically.

Futaba users can select different slots using PowerBox Terminal. For HoTT and Multiplex systems it is possible to set up various alarms for altitude or distance.

With most systems the GPS III can display additional information, such as the number of satellites, the accuracy of the positional information and the 2D distance.

The new unit utilises the proven Helix Radial antenna introduced with the GPS II. This provides an important feature which is unique to the PowerBox GPS: it is the only unit to guarantee GPS reception in all flight attitudes.

Features

  • Latest generation of GPS
  • Helix antenna for reception regardless of flight attitude
  • Reception even under difficult conditions
  • Fast response to speed changes
  • Automatic system detection
  • LED status indicator
  • Accurate 3D speed
  • Height measurement (altimeter)
  • Distance, optionally as 2D or 3D value
  • Distance covered
  • Geo-coordinates
  • Number of satellites, measurement accuracy
  • Supports the following telemetry systems:
    PowerBox CORE P²BUS
    iGyro/Royal SRS/Mercury
    Futaba S.BUS2
    Multiplex M-LinkJeti EX-BUS
    Graupner HoTT

Technical Data

Operating voltage 4.0 V - 9.0 V
Current drain Power-on state max. 60 mA
Supported RC systems Royal, Mercury, iGyro 3xtra, iGyrio SRS
Dimensions 58 x 18 x 17 mm
Weight 14 g
Temperature range -30 °C to +75 °C
